Thermal Solutions for Electronics
Custom die-cut thermally conductive tapes for heat sinks and compact assemblies
Electronic devices need protection from their own byproduct, which is heat. Thermal solutions from iD Products start with the right material and the right fit. Our die cut 3M™ thermally conductive tapes provide reliable gap filling that fits tight assemblies, installs quickly and maintains a secure hold. Our custom die-cut solutions help reduce manufacturing costs up front while protecting device performance over the long term. That’s the value of working with iD Products.
How thermal issues become product issues
There’s no getting around the fact heat builds inside electronic devices. When thermal management materials fail to remove it, product performance starts to lag and eventually fails.
ROOT CAUSES INCLUDE:
Overheating:
Prolonged exposure degrades semiconductors and shortens component life.Poor interface contact:
Microscopic air gaps form between surfaces, trapping heat.Material movement:
Caused when incompatible materials are exposed to thermal cycling and vibration.Adhesive failure:
Long-term heat and mechanical stress can compromise durability.Assembly inefficiencies:
Difficult-to-handle pastes can slow installation and create inconsistent applications.Reliable thermal transfer: Building a system that beats the heat
Your thermal transfer adhesives are part of a larger thermal management system. Together, different properties and requirements support manufacturability, product performance and long-term reliability.
Thermal path: Effectively channels heat toward cooling surfaces.
Surface conformability: Excellent wet-out on uneven surfaces to reduce heat-trapping air gaps.
Adhesion hold: Maintains long-term holding power under heat and vibration.
Interface thickness: The right tape thickness ensures coverage while minimizing thermal resistance and pressure on delicate components.
Dielectric requirements: Combines electrical insulation with thermal conductivity in thin profile designs.
Assembly and handling:
Designed for clean installation and tight tolerances in either manual or automated assemblies.
Common adhesive thermal solutions for electronics
iD Products partners with OEMs to help them create thermal transfer systems for electronic assemblies. We source and stock high-performance thermally conductive pressure-sensitive adhesives from 3M™ and other leading brands, then precision die cut them for reliable fit.
Bonding heat sinks
Thermally conductive tapes establish a reliable thermal path between components or circuit boards to heat sinks.
Fastening heat spreaders
Double-sided adhesive tapes bond and conform while channeling the heat and eliminate the need for metal fasteners.
Replacing messy thermal paste
Pressure-sensitive thermal transfer tapes provide faster, cleaner, more repeatable installation.
Combining heat transfer with electrical insulation
Ideal for tight assemblies and low profile electronics.
Die-cut thermal parts for efficient assembly
Technical Specifications for Thermal Solutions
As you narrow your choice of materials, use this at-a-glance reference to evaluate fit and die-cutting requirements to create your custom thermal management system.
Thermally conductive tape options
- Thermally conductive transfer tapes
- Double-sided thermally conductive tapes
- Thermal interface materials (TIMs)
- Ceramic-filled adhesive tapes
- Electrically insulating thermal materials
Thermal performance considerations
- Thermal conductivity requirements
- Interface thickness
- Surface conformity and wet-out
- Gap filling requirements
- Thermal cycling exposure
- Thermal resistance
Handling and assembly considerations
- Manual and automated assembly
- Compact assemblies
Die-cutting and part formats
- Custom die-cut parts
- Kiss-cut rolls
- Sheeted parts
- Tight-tolerance converting
Adhesion and durability
- Adhesive type
- Holding strength
- Heat and vibration resistance
- High-temperature performance
- Environmental exposure
Dielectric properties
- Electrically insulating constructions
- Materials for sensitive electronic assemblies
- Thin- or low-profile thermal management applications
Our Process: Building your thermal management solution
There’s a lot riding on your electronic device. iD Products is here to help you finalize and scale your thermal transfer solution.
Quality support and supply support for custom thermal solutions
Thermal management materials demand some of the highest performance standards in your product. Material selection is just the first step. Consistent converting is key to long term product reliability.
As an ISO 9001:2015-certified facility, iD Products backs every job with best in industry processes and standards to support your long-term production demands.
Repeatable: Close tolerance die cutting to ensure reliable thermal protected coverage with every installation.
Inspection and quality checks: Materials and converted parts are inspected for dimensional accuracy and overall quality.
Configuration control: As designs and performance requirements evolve, our processes support revisions and changes along the way.
Supply continuity: Partnerships with top brands like 3MTM ensure responsive lead times.
FAQs about custom thermal conductive tapes
How do I choose the right thickness of thermally conductive tape?
Thermally conductive tapes are compressible and provide gap filling between components and heat transfer surfaces. However, choosing a tape that’s too thick can add excess pressure on delicate components while also increasing thermal resistance. The best approach in choosing the right thickness of thermally conductive tape is to choose the thinnest material possible that fills the gap while maintaining surface contact.
Are there adhesive tapes that provide both heat transfer and electrical insulation?
Some high-performance thermally conductive tapes are filled with ceramic particles that help transfer heat while maintaining electrical insulation. These materials are commonly used in electronic assemblies that require both thermal management and dielectric protection.
What’s the difference between thermally conductive tape and thermal paste?
Thermally conductive tapes provide cleaner handling, repeatable placement and simplified assembly compared to thermal pastes. While thermal pastes are commonly used for gap filling and interface contact, adhesive thermal tapes can help reduce mess, improve consistency and support faster installation.
What’s the advantage of die-cut thermal materials?
Die-cut thermal materials improve placement accuracy, fit and handling while reducing installation time and material waste. Precision converting also helps support repeatable thermal coverage across production runs.
What factors affect thermal transfer performance?
Thermal transfer performance depends on more than conductivity ratings alone. Interface thickness, surface conformity, contact pressure, adhesion and environmental conditions all influence how effectively heat moves through an assembly.
Partner with iD Products for thermally conductive solutions
As you refine the design of your electronic device, iD Products can help you build the right thermal management system for efficient assembly and long-term performance. Share your thermal management requirements, including bonding applications, gap-filling needs and production specifications. Our specialists will help identify the right thermally conductive materials and converting process for your application.
